Sonora LA141R-T SWM 14dB Gain Line Amp with 12V Power Supply

UPC:
609465598949
MPN:
LA141R-T
Condition:
New
Shipping:
Calculated at Checkout
MSRP: $109.99
$84.95
— You save $25.04

Description

Sonora LA141R-T SWM 14dB Gain Line Amp with 12V Power Supply

Model LA141R boosts cable and DBS signal levels
off setting the loss of 150 feet of RG-6 while passing
data modem and receiver control signals from the
receiver to the switch.

SWM (MFH2) Line Amp 14dB gain, 54 to 3500 MHz, with sub band return 2 to 40 MHz, with external power port.

The LA141R is perfect for use on the SWM-8. Use if the output of a Single Wire Multi-switch is split to multiple rooms or apartments and the receiver signal levels are low after over 200 feet of RG-6 cable.

The LA141R boosts basic cable and DBS signal level off-setting the loss of an 8-way splitter while passing data modem and receiver control signals from the receiver to the switch.

This product is a universal coaxial amplifier. If you were to carry a single amplifier this would be the one. The amp works with Digital, CATV, consumer DBS, commercial MFH1 & MFH2 stacked DBS, and satellite radio.

Approved by DIRECTV & Dish Network



Specifications:

  • SWM8 Output line amp
  • 14 dB gain
  • 54 to 3500 MHz
  • Sub-band return 2 to 40 MHz
  • Includes 12v 200mA transformer





LA141R Specifications
