Sonora HRvT210 High Performance 10 dB Vertical Tap 2-Port 2-2400 MHz

Sonora HRvT210 High Performance 10 dB Vertical Tap 2-Port 2-2400 MHz

SITUATION
DBS Ka/Ku or ATSC off-air signals are required at multiple locations connected via coax cable. Signal must be directional coupled from the trunk to conserve trunk signal level while providing suffi cient tap levels.

SOLUTION
Models HRT*, HRvT*, & HRwT* placed in the trunk “tap” a portion of the signal from the trunk while isolating the tap port from the trunk.

RELATED CONSIDERATIONS
Tap input and output return loss is critical to maintain signal integrity. SONORA taps feature high return loss for excellent match.

Tap isolation is critical in large distribution systems to prevent reflections from exiting the tap port. SONORA taps feature isolation.

• 10 dB, 2-port tap, vertical
• 15 to 2150 MHz
• High Return Loss
• DC passive In/Out
• Die cast indoor/outdoor case
